Description
General
- Phase: Single Phase
- Form Factor: Tower
- UPS Topology: Line-interactive
Input
- Generator Compatibility: Yes
- Nominal Input Voltage ( Vac ): 230 ± 10%
- Input Voltage Range ( Vac ): 140 ~ 300
- Input Frequency ( Hz ):
50 ± 10
60 ± 10 - Input Frequency Detection: Auto-sensing
- Rated Input Current ( A ): 2.83
- Input Connector Type: IN/ZA
- Power Cord Length (ft.): 4
- Power Cord Length (m.): 1.2
Output
- Capacity (VA): 650
- Capacity (Watts): 360
- On Battery Waveform: Simulated Sine Wave
- On Battery Voltage(s) ( Vac ): 230 ± 10 %
- On Battery Frequency ( Hz ):
60 ± 1%
50 ± 1% - Automatic Voltage Regulation (AVR): Double Boost, Single Buck
- Overload Protection: Internal Current Limiting
- Outlet(s) – Total: 3
- Outlet Type: IN/ZA x 3
- Outlet(s) – Battery Backup: 3
- Typical Transfer Time ( ms ): 4
Battery
- Runtime at 60W ( min ): 33
- Runtime at 90W ( min ): 19
- Typical Recharge Time ( Hours ): 8
- Start On Battery: Yes
- User-replaceable: No
Surge Protection & Filtering
- EMI/RFI Filtration: Yes
Management & Communications
- LED Indicators: Power On
- Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Physical
- Enclosure Construction: Plastic
- Color: Black
Physical Size – UPS Module
- Dimensions (WxHxD) (in.): 3.31 x 6.85 x 11.02
- Dimensions (WxHxD) (mm.):84 x 174 x 280
- Weight (lbs.): 8.82
- Weight (kg.): 4.0
Shipping Dimensions
- Dimensions (WxHxD) (in.): 4.29 x 9.02 x 12.4
- Dimensions (WxHxD) (mm.): 109 x 229 x 315
- Weight (lbs.): 9.1
- Weight (kg.): 4.13
Environmental
- Operating Temperature (°F): 32 ~ 104
- Operating Temperature (°C): 0 ~ 40
- Operating Relative Humidity (Non-condensing) ( % ): 0 ~ 90
- Operating Elevation ( feet/meters ): 0-9,843 feet (0-3,000 meters)
- Storage Temperature (°F): -4 ~ 122
- Storage Temperature (°C): -20 ~ 50
- Storage Relative Humidity (Non-condensing) ( % ): 0 ~ 90
- Storage Elevation ( feet/meters ): 0-9,843 feet (0-3,000 meters)
- Online Thermal Dissipation ( BTU/hr ): 24
Certifications
- Certifications: BIS
- RoHS: Yes
